| Channel No. | 16-ch |
| Decoding Format | H.265+/H.265/H.264+/H.264 |
| Incoming/Outgoing Bandwidth | 160/80Mbps |
| Decoding Capacity | 1-ch@12MP(20 fps), 2-ch@8MP(30 fps)/4-ch@4MP(30 fps)/8-ch@1080p(30 fps) |
| Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/D1/4CIF |
| Display | 1 HDMI/1 VGA supports simultaneous video sources output for VGA and HDMI |
| Storage Capacity | 2 SATA interfaces, up to 12 TB capacity for each HDD |
| Video Output | HDMI: 1-ch, 4K (3840 x 2160)/30Hz, 2560x1440@60Hz, 1920 x1080/60Hz, 1600 x1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz VGA:1-ch, 1920 x1080/60Hz, 1600 x1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz |
| Audio I/O | 1/1 |
| Alarm I/O | 4/2 |
| Network Interface | 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces |
| PoE Port (/P) | N/A |
| USB Port | 2 (1 x front USB.2.0; 1 x back USB2.0) |
| Smart Function | AI by recorder supports 4-channel SMD, AI by camera supports SMD(Human/Vehicle), intrusion, tripwire, people counting, heat map and face capture for all channels |
| Power Consumption (without HDD) | < 10 W (without HDD) |
| Power Supply | 12VDC, 4A |
| Dimension | 375 × 327.2 × 54mm (14.8″ × 12.83″ × 2.13″) |
| Working Temperature | - 10 °C to 55 °C (14 ° F to 131 ° F) |
| Certification | FCC CE |
